Waters/VG/Micromass Accessories (Catalog B23)

Home

Hover over image to zoom

B23

Waters/VG/Micromass Accessories

FAX: 908-806-6631

www.sisweb.com

Waters DCI Probe Tip Repair

The platinum heater coils on the VG probe tip can be replaced.

Our repair consists of sand blasting and cleaning the entire probe

tip assembly and then spotwelding a new three coil platinum fila-

ment to the posts.

Viton ‘O’-Rings for Waters Instruments

(Pkg of 10)

Copper Gaskets for Waters Instruments

VG part numbers vary with the instrument. Use dimensions to

determine compatibility.

Gold ‘O’-Rings for Waters Instruments

All gold ‘O’-Rings are constructed from .020” diameter pure

gold wire.

Part No.

VG Part No.

I.D. x Thick (in.)

V-258 Part #V258—Click for details
DISCONTINUED
Unit of Measure: EA
Est. Ship Weight=0.003 lbs

5711004

5.98 x .139

V-119 Part #V119—Click for details
DISCONTINUED
Unit of Measure: EA
Est. Ship Weight=0.003 lbs

5711009

.924 x .103

V-118 Part #V118—Click for details
Current Price: $1.02
(100 or more: 40% off; 1000 or more: 60% off)
Unit of Measure: EA
Est. Ship Weight=0.003 lbs
Quantity in Stock=8

5711010

.862 x .103

V-117 Part #V117—Click for details
DISCONTINUED
Unit of Measure: EA
Est. Ship Weight=0.003 lbs

5711013

.799 x .103

V-113 Part #V113—Click for details
DISCONTINUED
Unit of Measure: EA
Est. Ship Weight=0.003 lbs

5711015

.549 x .103

V-112 Part #V112—Click for details
Current Price: $0.75
(100 or more: 40% off; 1000 or more: 60% off)
Unit of Measure: EA
Est. Ship Weight=0.003 lbs
Quantity in Stock=13

5711016

.487 x .103

V-013 Part #V013—Click for details
Current Price: $0.53
(100 or more: 40% off; 1000 or more: 60% off)
Unit of Measure: EA
Est. Ship Weight=0.003 lbs
Quantity in Stock=121

5711017

.426 x .070

V-011 Part #V011—Click for details
Current Price: $0.45
(100 or more: 40% off; 1000 or more: 60% off)
Unit of Measure: EA
Est. Ship Weight=0.003 lbs
Quantity in Stock=31

5711018

.301 x .070

V-009 Part #V009—Click for details
Current Price: $0.42
(100 or more: 40% off; 1000 or more: 60% off)
Unit of Measure: EA
Est. Ship Weight=0.003 lbs
Quantity in Stock=105

5711020

.208 x .070

V-007 Part #V007—Click for details
Current Price: $0.40
(100 or more: 40% off; 1000 or more: 60% off)
Unit of Measure: EA
Est. Ship Weight=0.003 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.

5711022

.145 x .070

V-236 Part #V236—Click for details
Current Price: $5.09
(100 or more: 40% off; 1000 or more: 60% off)
Unit of Measure: EA
Est. Ship Weight=0.003 lbs
Quantity in Stock=385

5711027

3.23 x .139

V-148 Part #V148—Click for details
DISCONTINUED
Unit of Measure: EA
Est. Ship Weight=0.003 lbs

5711028

2.74 x .103

V-014 Part #V014—Click for details
Current Price: $0.54
(100 or more: 40% off; 1000 or more: 60% off)
Unit of Measure: EA
Est. Ship Weight=0.003 lbs
Quantity in Stock=161

5711031

.489 x .070

V-018 Part #V018—Click for details
DISCONTINUED
Unit of Measure: EA
Est. Ship Weight=0.003 lbs

5711033

.739 x .070

V-144 Part #V144—Click for details
DISCONTINUED
Unit of Measure: EA
Est. Ship Weight=0.003 lbs

5711040

2.49 x .103

V-215 Part #V215—Click for details
DISCONTINUED
Unit of Measure: EA
Est. Ship Weight=0.003 lbs

5711043

1.05 x .139

V-234 Part #V234—Click for details
DISCONTINUED
Unit of Measure: EA
Est. Ship Weight=0.003 lbs

5711054

2.98 x .139

Part No. VG No.

O.D. x I.D.

CG500 Part #CG500—Click for details
Current Price: $3.95
(10 or more: 5% off; 50 or more: 10% off)
Unit of Measure: EA
Est. Ship Weight=0.04 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.

6061304

48mm x 38mm

CG1000 Part #CG1000—Click for details
Current Price: $4.75
(10 or more: 5% off; 50 or more: 10% off)
Unit of Measure: EA
Est. Ship Weight=0.1 lbs
Quantity in Stock=22

6061305

82mm x 64mm

CG1900 Part #CG1900—Click for details
Current Price: $8.50
(10 or more: 5% off; 50 or more: 10% off)
Unit of Measure: EA
Est. Ship Weight=0.22 lbs
Quantity in Stock=84

6061307

171mm x 150mm

Part No.

VG Part No.

I.D.

VGG-2 Part #VGG2—Click for details
Current Price: $87.24
Unit of Measure: EA
Est. Ship Weight=0.25 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.

6017002

45 mm

VGG-3 Part #VGG3—Click for details
Current Price: $105.86
Unit of Measure: EA
Est. Ship Weight=0.25 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.

6017003

54 mm

VGG-4 Part #VGG4—Click for details
Current Price: $124.51
Unit of Measure: EA
Est. Ship Weight=0.25 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.

6017004

63 mm

VGG-5 Part #VGG5—Click for details
Current Price: $292.10
Unit of Measure: EA
Est. Ship Weight=0.25 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.

6017005

150 mm

VGG-6 Part #VGG6—Click for details
Current Price: $41.56
Unit of Measure: EA
Est. Ship Weight=0.25 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.

6017006

20.5 mm

VGG-7 Part #VGG7—Click for details
Current Price: $207.46
Unit of Measure: EA
Est. Ship Weight=0.25 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.

6017007

105 mm

VGG-8 Part #VGG8—Click for details
Current Price: $41.56
Unit of Measure: EA
Est. Ship Weight=0.25 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.

1013018

6.95 mm

VGG-9 Part #VGG9—Click for details
Current Price: $41.56
Unit of Measure: EA
Est. Ship Weight=0.25 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.

1013017

9.9 mm

VGG-10 Part #VGG10—Click for details
Current Price: $67.74
Unit of Measure: EA
Est. Ship Weight=0.25 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.

1013019

6.35 mm

VGG-11 Part #VGG11—Click for details
Current Price: $42.34
Unit of Measure: EA
Est. Ship Weight=0.25 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.

1013022

20.57 mm

VGG-12 Part #VGG12—Click for details
Current Price: $41.56
Unit of Measure: EA
Est. Ship Weight=0.25 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.

18.5 mm

6 Hole Ceramic Tubing

For the repair or manufacture of the VG heaters listed above,

this alumina ceramic tubing has 6 holes bored lengthwise with

each hole approximately 0.50 mm in diameter. Its available in

6.0" lengths with other lengths available on special request.

Part No.

Description

VGHC6 Part #VGHC6—Click for details
DISCONTINUED
Unit of Measure: EA
Est. Ship Weight=0.25 lbs

6 Hole ceramic, 6" long

Waters Instrument Sample Vials

These Pyrex glass vials are 1.7 mm O.D. x 1.3 mm I.D. x 20 mm

long. Order in higher quantities for greater savings.

Waters Direct Probe Tips

SIS™ has redesigned the VG direct probe ceramic probe tip which

holds the sample vials in place on the end of the probe. The VG

originals were two pieces (VG #7025102 and #7050203). These

were machined from soft MACOR ceramic. We have changed this

to a one piece design for simplicity and ease of use. We have a

hard alumina ceramic version and a Vespel type. The vespel is

more durable; however, the heat transfer is not as good.

Part No.

Description

VGV-100 Part #VGV100—Click for details
DISCONTINUED
Unit of Measure: PK
Est. Ship Weight=0.05 lbs

100 Sample Vials

VGV-500 Part #VGV500—Click for details
Current Price: $265.00
Unit of Measure: PK
Est. Ship Weight=0.25 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.

500 Sample Vials

VGV-1000 Part #VGV1000—Click for details
Current Price: $502.00
Unit of Measure: PK
Est. Ship Weight=0.5 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.

1000 Sample Vials

Part No.

Description

VG50C Part #VG50C—Click for details
Current Price: $135.00
Unit of Measure: EA
Est. Ship Weight=0.25 lbs
Quantity in Stock=3

Ceramic VG direct probe tip

VG50V Part #VG50V—Click for details
Current Price: $0.00
Unit of Measure: EA
Est. Ship Weight=0.25 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.

Vespel VG direct

probe tip

Part No.

Description

FILREP

Filament Repair, VG Probe Tip

New

ESI Source Parts

The following products are compatible with the ESI Probe

Capillary & Perlast O-Ring: LCT Premier/XE, QTof API US &

Ultima Family, Quattro LC, Micro API, Premier/XE, Ultima, Ultima

Pt, SQ Detector & Detector 2, TQ Detector, Synapt G2 HDMS,
