Part No. Thermo #

Description

O.D.

I.D.

Thick.

Price ea. 10 or more/ea.

04002-20170

Ceramic Insulator

.087"

.063"

.065"

Z11

04002-20160

Ceramic Insulator

.087"

.063"

.095"

30004-20030

Ceramic Insulator

.087"

.063"

.0125"

Z13

01554-20040

Ceramic Insulator

.087"

.063"

.160"

Z31

55000-20014

Ceramic Bushing

.087"

.063"

.175"

40004-20390

Ceramic Insulator

.087"

.063"

.200"

Z10

30004-20040

Ceramic Insulator

.087"

.063"

.360"

Z12

01554-20030

Ceramic Insulator

.087"

.063"

.425"

Z32

55000-20065

Ceramic Bushing

.087"

.063"

.760"

00301-20104

Alumina Tube

.100"

.050"

2.31"

00301-20100

Alumina Tube

.100"

.050"

4.00"

00301-20200

Alumina Tube

.100"

.050"

5.00"

07504-21108

Sapphire Spacer

.156"

.094"

.030"

Z14

40004-20460

Ceramic Insulator

.156"

.095"

.050"

40004-20730

Ceramic Insulator

.156"

.090"

.088"

Z26

30004-20020

Ceramic Insulator

.156"

.093"

.100"

Z15

40004-20430

Ceramic Insulator

.156"

.095"

.117"

Z17

30004-20010

Ceramic Insulator.

156"

.095"

.250"

Z16

40004-20340

Ceramic Insulator

.156"

.095"

.280"

40004-20440

Ceramic Insulator

.230"

.140"

.035"

Z42

94022-20012

Ceramic Bushing, ITD

.250"

.090"

.160"

Z19

01554-20020

Ceramic Insulator

.250"

.125"

.064"

Z18

01554-20010

Ceramic Insulator

.365"

.250"

.064"

40004-20510

L1 Ceramic Spacer

.560"

.406"

.030"

Z27

Ceramic Gate Insulator (Ion Trap)

.683"

.530"

.120"

NSI1

40004-20710

Thermo 4000 Sapphire

.935"

.750"

.031"

BE2

40005-20070

Beryllium Oxide Ceramic

1.15"

.895"

.078"

CE2

40005-20070

Aluminum Oxide

1.15"

.895"

.078"

BE1

40005-20060

Beryllium Oxide Lens Castle for Thermo 4500 Source

FRI4

40004-20400

Source End Insulator Ring for Thermo 4000 Source

Z28

94011-20112

Position Pin Insulator

Z29

94011-20133

ITD Electrode Spacer

Z27A

94011-20008

Gate Insulator

.683"

.526"

.120"

Z28A

94011-20171

Position Pin

VGI33

Co46M

Alumina Ceramic Insulator

CE2, BE2

Ceramic and Sapphire Insulators

e are constantly adding insulators for Thermo and other
manufacturer's instrument systems. The following alumina
insulators are currently available. If other sizes and/or

types are required, please give us a call or send an old or damaged unit,
and we will see if we can supply it. All listed insulators are constructed
from a high quality aluminum oxide ceramic, unless otherwise noted.
Additional ceramic and sapphire insulators are listed in the ceramics
section of this catalog.

Scale Drawing of Thermo Ceramic Insulators

Z42

*When "Thermo" is indicated, it is intended to imply "Thermo Fisher Scientific Corp"

VGI-33

Related information may be found on the following pages of our web site:

Page	Parts
Finnigan Ion Trap Ceramic Insulators	Z28, Z29, Z27A, Z28A, Z42, Z27
Finnigan 4500 Lens Retainer Ring	CE2, BE2
Ceramic Insulators for Finnigam MAT MS	Z10, Z11, Z12, Z13, Z14, CE2, Z31, Z15, Z32, Z16, Z17, Z18, Z19, Z27A, R1, R2, R4, BE1, BE2, Z1, Z2, Z4, Z5, Z26, Z42, Z7, Z27, Z8, Z28, Z9, Z29, Z28A, NSI1, FRI4
Nermag Mass Sspec Ceramics	Z13
Finnigan 4500 Lens Castle Ceramic	BE1
Finnigan 4000 Source End Insulator Ring	FRI4
Ceramic Insulators for Finnigan Incos Mass Spec	Z31, Z32, Z5, Z26
Ceramic Insulators for VG Fisons MS	VGI33
Finnigan 4000 Nozzel Spring Insulator	NSI1
