Digivac Vacuum Gauge Model 276

Digivac Bench Top Vacuum Gauge Model 276
Hover over image to zoom
Price: 620
Product ID : M276
M276 MODEL 276

Description

Super Accurate Dual Sensor Technology from 1 milliTorr to 760 Torr

The Digivac Model 276 produces reliable, consistent accuracy from 1 milliTorr through 760 Torr (atmospheric pressure). The 276 leverages dual sensor technology that has the unique ability to accurately measure through the entire rough vacuum range from 1 milliTorr through760 Torr. This instrument builds on the simplicity and success of our best selling vacuum gauge - Model 200. We do this through a seamless combination of sensing technologies integrated into a single easy to use bench top unit. The Model 276 is the same size as the Model 200; however the Model 276 adds high accuracy in the Torr ranges and accuracy approaching a capacitance manometer in the range of 10 Torr to 760 Torr/Atmosphere. This unit is also available with the ability to log to a web page, Ethernet connectivity, RS232 communications, PC software that displays, plots and logs, and an analog recorder out. The 276 is also less sensitive to the composition of gasses, since it uses piezoelectric transducer technology in the 3-760 Torr range.

Specs

Specifications
Range.001 - 760
UnitsTorr
Vac Interface1/8" MNPT or KF/NW
Sensor276T
Sensor Cable Length10 Feet
Display.56" high 3.5 Digit Red LED
Dimensions1.5" high, 4.25" wide, 5.5" deep
Analog Output(if applicable):0 - 5 VDC
Power10 - 240 VAC, 50/60 Hz, CE Rated
Controls7 Amp, 250 Volt (if applicable)
