Edwards EM Series Pumps

E2M18 Vacuum Pump

Technical Data
Displacement (swept volume) 50 Hz	12.1 ft³ min^-1 (20.5 m³ h^-1)
Displacement (swept volume) 60 Hz	14.7 ft³ min^-1 (25.0 m³ h^-1)
Speed (Pneurop) 50 Hz	10 ft³ min^-1 (17.0 m³ h^-1)
Speed (Pneurop) 60 Hz	12 ft³ min^-1 (20.4 m³ h^-1)
Ultimate vacuum (partial pressure) without gas ballast	7.6 x 10^-5 torr (10^-4 mbar)
Ultimate vacuum (partial pressure) with gas ballast	3.8 x 10^-3 torr (5 x 10^-3 mbar)
Inlet connection	NW25
Outlet connection	Nozzle 15 mm external diameter removable from hole tapped 3/4 inch BSP
Maximum permitted pressure at outlet	7 psig (0.5 bar gauge)
Maximum inlet pressure forwater vapor	15 torr (20 mbar)
Maximum water vapor pumping rate	0.30 kg h^-1
Weight	79 lbs (36 kg)
Motor power 50 Hz	0.55 kW
Motor power 60 Hz	0.75 kW
Oil Capacity maximum	1.05 liter
Oil Capacity minimum	0.75 liter

Part No.	Description	UOM	est wt.	Quantity In Stock	Price
A36315981	Edwards E2M18 Vacuum Pump	EA	70	0^{[*L]Standard lead-time for out-of-stock items is approximately two weeks depending on the item.}	$4644.00
[*L] Standard lead-time for out-of-stock items is approximately two weeks depending on the item.
Ordering information. International (non-US) prices available through your local dealer.

E2M28 Vacuum Pump

Technical Data
Displacement (swept volume) 50 Hz	19 ft³ min^-1 (32.2 m³ h^-1)
Displacement (swept volume) 60 Hz	22.3 ft³ min^-1 (38.9 m³ h^-1)
Speed (Pneurop) 50 Hz	16.2 ft³ min^-1 (27.5 m³ h^-1)
Speed (Pneurop) 60 Hz	19.5 ft³ min^-1 (33.0 m³ h^-1)
Ultimate vacuum (partial pressure) without gas ballast	7.5 x 10^-5 torr (10^-4 mbar)
Ultimate vacuum (partial pressure) with gas ballast	3.4 x 10^-3 torr (5 x 10^-3 mbar)
Inlet connection	NW25
Outlet connection	Nozzle 15 mm external diameter removable from hole tapped 3/4 inch BSP
Maximum permitted pressure at outlet	7 psig (0.5 bar gauge)
Maximum inlet pressure for water vapor	23 torr (30 mbar)
Maximum water vapor pumping rate	0.7 kgh^-1
Weight	40 kg
Motor power 50 Hz	0.75 kW
Motor power 60 Hz	0.90 kW
Oil Capacity maximum	1.5 liter
Oil Capacity minimum	1.2 liter

Part No.	Description	UOM	est wt.	Quantity In Stock	Price
A37317984	EDWARDS E2M28 115/230V UNIVERSAL MOTOR	EA	70	0^{[*L]Standard lead-time for out-of-stock items is approximately two weeks depending on the item.}	$5717.00
[*L] Standard lead-time for out-of-stock items is approximately two weeks depending on the item.
Ordering information. International (non-US) prices available through your local dealer.

SIS Catalog Cross Reference
Page #	Part Numbers
F30 - BOC Edwards EM Vacuum Pumps	A36315981, A37317984
