Infuse only single syringe pump. Accommodates syringes from 0.5µl to 10ml. User definable flow rates with selectable target volume or time values to control the total infusion volume.
| Specifications | |||
|---|---|---|---|
| Accuracy | +/- 0.5% | Reproducibility | +/-0.05% |
| Syringes (min/max) | 0.5µl to 10 ml | Flow Rate |
|
| Display (min/max) | 4.3 WQVGA TFT Color Display with Touchpad |
Non-Volatile Memory | Stores all Settings |
| Connectors (min/max) |
|
Linear Force (Max) | 13.6 kg (30lbs)@ 100% Force Selection |
| Drive Motor | 0.9 Stepper Motor | Motor Drive Control | Microprocessor with 1/16 microstepping |
| Number of Microsteps per one rev. of Lead Screw | 15,360 | Step Revolution | 0.069 µm/step |
| Step Rate - Minimum | 27.5 sec/µstep | Step Rate - Maximum | 26 µsec/µstep |
| Pusher Travel Rate - Minimum | 0.15µm/min. | Pusher Travel Rate - Maximum | 159 mm/min |
| Power | 100 - 240 VAC: 50/60Hz, 50W, 0.5A fuse | Dimensions | 22.6 cm x 19.05 cm x 15 cm (9" x 7.5" x 5 ") |
| Weight | 2.66 kg (5.9 lbs.) | Operating Temperature | 4° C to 40° C (40° F to 104° F) |
| Storage Temperature | -10° C to 70° C (14° F to 158° F) | Humidity | 20% to 80% RH non condensing |
| Part No. | Description | UOM | est wt. |
Quantity In Stock |
Price | Quantity to order |
|---|---|---|---|---|---|---|
| 788101 | Legato 101 Dual Syringe Infuse Only; Legato 101; 110V/220V | EA | 0 | 0[*L]Standard lead-time for out-of-stock items is approximately two weeks depending on the item. | $2060.00 | |
| [*L] Standard lead-time for out-of-stock items is approximately two weeks depending on the item. | ||||||
Ordering information.
International (non-US) prices available through your
local dealer.
|
||||||
