KD Scientific Dual Rate Syringe Pumps

Home
KD Scientific KDS Gemini 88 Dual Rate Syringe Pump
Hover over image to zoom

Decription

The NEW KDS Gemini 88. This unique pump is really two pumps in one. Each side of the Gemini 88 has its own syringe rack, motor and leadscrew. The pump can infuse simultaneously at different rates, or infuse with one syringe and withdraw with the other. When combined with a valve box it provides continuous delivery.

The Gemini Syringe Pump offers continuous infusion or withdrawal, 24 hours a day, 365 days a year with the accuracy and low flow of a KD Scientific syringe pump.

Features

  • Continuous delivery 24/7
  • RS232 computer interface
  • Daisy chain up to 100 pumps
  • Wide variety of syringes from 0.5 µl - 140 mL
  • High or low pressure
  • CE certification
  • TTL interface
  • 57 lbs of linear force
  • 12 month warranty

Specs

Specifications
Accuracy 0.35%
No. of Syringes 2
Syringe Size (Min./Max/) 0.5 µl to 140 mL
Display LED, 5 digit, numeric
Communications RS-232, TTL
Communications Level 2
Flow Rate (Min./Max) 0.0004 µl/hr / 106.6 mL/hr
Average Linear Force 57lbs
Non Volatile Memory Storage of all settings
RS-232 RJ11-4 connector
TTL 9-pin connector
Input Power 36 VDC 1.4 Amps
Drive Motor 2 motors, 1/2 to 1/4 microstepping, microprocessor controlled, 0.9 ° step angle
Motor Stepping 1,600 at 1/2 stepping, 3,200 at 1/4 stepping revolution of lead screw
Step Resolution 0.33 µm/step
Step Rate (Min/Max) 27.3 sec/step to 416.7 µsec/step
Pusher Travel Rate 0.726699 µm/min to 95.25 mm/min
Voltage Range Selectable, 95 to 130 VAC, 60 Hz or 220 to 260 VAC, 50 Hz
Dimensions 31.1 cm x 28.6 cm x 15.2 cm (12.5" x 11.25" x 6")
Weight 6.8 kg (15 lbs.)
Part No. Description Quantity
In Stock
Price
EA
Order
780388 Gemini 88 Independent Dual Rate Pump System, Gemini 88, 110V/220V DISCONTINUED------
