| Technical Data | ||
|---|---|---|
| Inlet connection | DN 40 ISO-KF | |
| Outlet connection | DN 40 ISO-KF | |
| Nominal pumping speed at 50 Hz | 42.0 m3/h (24.8 cfm) | |
| Nominal pumping speed at 60 Hz | 50.0 m3/h (29.5 cfm) | |
| Pumping speed at 50 Hz | 40.0 m3/h (23.6 cfm) | |
| Pumping speed at 60 Hz | 48.0 m3/h (28.3 cfm) | |
| Ultimate partial pressure without gas ballast | ≤5.0 x 10-2 mbar (≤3.75 x 10-2 torr) | |
| Ultimate total pressure without gas ballast | ≤5.0 x 10-2 mbar (≤3.75 x 10-2 torr) | |
| Ultimate total pressure with gas ballast | ≤5.0 x 10-1 mbar (≤3.75 x 10-1 torr) | |
| Water vapor tolerance at 50 Hz | 10.0 mbar (7.5 torr) | |
| Water vapor tolerance at 60 Hz | 10.0 mbar (7.5 torr) | |
| Water vapor capacity at 50 Hz | 280g/h | |
| Water vapor capacity at 60 Hz | 340 g/h | |
| Operating fluid | GS 32 | |
| Operating fluid capacity | 1.0 l (1.1 qt) | |
| Noise level to DIN 45 635 | ||
| without gas ballast | 59 - 62 dB (A) | |
| with gas ballast | - - - | |
| Mains connection | 3 ph, 230/400 V, 50 Hz 3-ph, 460 V, 60Hz |
|
| Motor rating at 50Hz | 1.1 kW (1.5 HP) | |
| Motor rating at 60 Hz | 1.3 kW (1.8 HP) | |
| Rotation speed at 50 Hz | 1.500 min-1 (1.500 rpm) | |
| Rotation speed at 60 Hz | 1.800 min-1 (1.500 rpm) | |
| Motor protection rating | IP 55-F | |
| Admissible ambient temperature | 12°C to40°C (54°F to 104%deg;F | |
| Weight | 43.0 kg (94.8 lbs) | |
| Part No. | Description | UOM | est wt. |
Quantity In Stock |
Price | Quantity to order |
|---|---|---|---|---|---|---|
| 960331 | LEYBOLD SV40 BI EURO PUMP | EA | 0 | 0(#) | $4300.00 | |
| (#) Standard lead-time for out-of-stock items is approximately two weeks. | ||||||
Ordering information.
International (non-US) prices available through your
local dealer.
|
||||||
