SIS Catalog Online

www.sisweb.com/catalog/08/B28

Thermo TRACE

™

Scientific Instrument Services, Inc.

™

Phone: 908-788-5550

T

he AutoProbe integrates a CTC liquid autosampler with
an automated Direct Exposure Probe (DEP) for the auto-
mated and unattended injection of dissolved or suspend-

ed samples directly into the Thermo DSQ, DSQ II, Polaris Q &
GCQ MS source for direct MS analysis. Using this technique, sam-
ples can be analyzed in about three minutes without any chro-
matographic separation. The AutoProbe is fully integrated with the
Thermo Xcalibur™ software, including system setup, methods
setup, system operation and data storage.

The DEP (or DCI) technique is used for the analysis of samples

that are not volatile enough to be introduced into the mass spec-
trometer via a GC and therefore must be directly introduced into the
mass spectrometer source. The DEP technique is normally used
for single component samples since minimal separation of samples
is possible with this technique and samples with two or more com-
ponents are difficult to interpret. Alternatively DEP sample analysis
is performed utilizing CI (Chemical Ionization) mass spectrometer
techniques, which produce less fragmentation in the mass spec-
trometer. Due to the increased abundance of a molecular ion and
reduced fragmentation in the CI technique, it is possible to analyze
and interpret mixtures of two or more compounds in a sample.

Part No. Thermo No.

Description

VGF5 Part #VGF5--Click to order
Current Price: $117.00
(6 or more: 5% off)
Unit of Measure: EA
Est. Ship Weight=0.25 lbs
Quantity in Stock=5

C030A

SIS VG MD800
filament

FILREP Part #FILREP--Click to order
Current Price: $39.00
(6 or more: 5% off)
Unit of Measure: EA
Est. Ship Weight=0.25 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.

Filament Repair

Filament for Thermo
TRACE

S

cientific Instrument Services

™

manu-

factures replacements for the VG
TRACE™ filaments which are similar

in design to the original. This new design is a
direct retrofit and incorporates a glass frit to
hold the posts in place.

Part No.

Thermo No.

Description

VGI33 Part #VGI33--Click to request quote
DISCONTINUED
Unit of Measure: EA
Est. Ship Weight=0.25 lbs

C046M

Alumina Ceramic Insulator

Ceramic Insulators

Scientific Instrument Services can sup-

ply replacement ceramic insulators for the
TRACE™ Source Lens. All insulators are
constructed from high purity alumina ceram-
ic.

AutoProbe

™

NEW - Automated Direct Exposure
Probe for Thermo Polaris Q,
DSQ, DSQ II, and
GCQ MS Systems

Syringe Needle Guide

Syringe Needle

Platinum DEP Coil

DEP Probe Tip

Part No.

Description

AP2000 Part #AP2000--Click to order
Current Price: $69950.00
Unit of Measure: EA
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.

AutoProbe System

AP20001 Part #AP20001--Click to order
Current Price: $325.00
Unit of Measure: EA
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.

AutoProbe DCI Filament

TRACE™ is a registered trademark of Thermo Fisher Scientific Corp

For More Details See Pages A57-A60

or

Visit the SIS Web Site

VGI-33 Part #VGI33--Click to request quote
DISCONTINUED
Unit of Measure: EA
Est. Ship Weight=0.25 lbs

B28
