Thermo
*
MS Source Cleaning by S.I.S.
™
B18
Scientific Instrument Services, Inc.
™
Phone: 908-788-5550
www.sisweb.com/catalog/08/B18
Expert Cleaning and Repair of Mass Spectrometer Sources
S
ince we first advertised this service in our January 1994
Newsletter, many of our customers have taken advan-
tage of source cleaning service. This is NOT an
exchange program. The same source that we receive from you,
is cleaned, repaired and returned back to you ready to install into
your mass spectrometer.
24 Hour Turnaround on Source Cleaning
For rush 24 hour turnaround, sources should be sent to S.I.S.
via Federal Express or other overnight carrier. Once received,
they will be cleaned and returned the next day via an overnight
carrier such as Federal Express. Please include your purchase
order. If your source is not one of the ones listed below, please
include a copy of the manufacturers assembly instructions and
schematic of the source assembly.
Service Notes
Source cleaning begins with the complete disassembly of the
source. The metal parts are cleaned and polished, then washed
in solvents and baked out in an oven. All ceramics insulators are
sandblasted followed by solvent washing and bake out. If broken
most of these ceramics can be replaced at no extra cost. Vespel
insulators are washed in solvent and baked out. If old filaments
are included on the source they are repaired at no extra charge.
Additional charges may be incurred if metal parts, source
heaters, or filaments damaged beyond repair need to be
replaced. If Vespel insulators are broken or missing, they will
need to be replaced at an additional cost.
After all parts have been repaired, cleaned and baked out the
source is reassembled. The filament is reinstalled and accurately
aligned over the source hole. The source is checked for resis-
tance leaks as well as visual alignment of all parts.
Shipping in for Repair
Normally the source block and associated parts are shipped
in for repair. The source should be thoroughly wrapped in pack-
aging material and double boxed to avoid damage in shipment. If
available, a copy of your source assembly/disassembly schemat-
ic from your mass spec manual should be sent in with your
source.
The SIS cleaning method is described on our web site:
www.sisweb.com/referenc/tips/msclean.htm
Part No.
Description
REP79 Part #REP79--Click to order
Current Price: $435.00
Unit of Measure: EA
Est. Ship Weight=3 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.
Source Cleaning of the Thermo MAT 4500/TSQ/SSQ 700 Source
REP78 Part #REP78--Click to order
Current Price: $435.00
Unit of Measure: EA
Est. Ship Weight=3 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.
Source Cleaning of the Thermo MAT 1020/OWA Source
REP75 Part #REP75--Click to order
Current Price: $450.00
Unit of Measure: EA
Est. Ship Weight=3 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.
Source Cleaning of the Thermo Delta Source
REP79 Part #REP79--Click to order
Current Price: $435.00
Unit of Measure: EA
Est. Ship Weight=3 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.
Source Cleaning of the Thermo TRACE Source
REP79 Part #REP79--Click to order
Current Price: $435.00
Unit of Measure: EA
Est. Ship Weight=3 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.
Source Cleaning of the Thermo MAT GCQ Source
REP75 Part #REP75--Click to order
Current Price: $450.00
Unit of Measure: EA
Est. Ship Weight=3 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.
Source Cleaning of the Thermo MAT 251 Source
REP78 Part #REP78--Click to order
Current Price: $435.00
Unit of Measure: EA
Est. Ship Weight=3 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.
Source Cleaning of the Thermo 3200/5100 Source
REP79 Part #REP79--Click to order
Current Price: $435.00
Unit of Measure: EA
Est. Ship Weight=3 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.
Source Cleaning of the Thermo DSQ & DSQ II Source
Thermo Source Cleaning
Thermo 4500/TSQ/SSQ 700 Source
Thermo 1020/OWA Source
Thermo Delta Source
Thermo 3200/5100
Source
Thermo TRACE Source
Additional Mass Spectrometer Sources Repaired
In addition to the Thermo sources listed above, SIS can clean and repair sources from any other mass spectrometers. Call SIS with
your requirements. We will clean and repair you mass spectrometer source.
Ceramic Insulator Cleaning
S.I.S. offers cleaning services for ceramic source insulators. The insula-
tors are first sandblasted with aluminum oxide, then with glass beads. This
two step process thoroughly removes any contamination or carbon residue.
Part No.
Description
REP98 Part #REP98--Click to order
Current Price: $48.00
Unit of Measure: EA
Est. Ship Weight=0.25 lbs
Standard lead time for non-stocked items is approximately two weeks.
Cleaning
Up to 20 Pieces
REP9H Part #REP9H--Click to order
Current Price: $95.00
Unit of Measure: PK
Est. Ship Weight=0.25 lbs
Standard lead time for non-stocked items is approximately two weeks.
Hourly Cleaning Rate
*When “Thermo” is indicated, it is intended to imply “Thermo Fischer Scientific Corp”
Related information may be found on the following pages of our web site:
PageParts
Thermo (Finnigan) Source Cleaning ServiceREP78, REP79
Finnigan MAT Ceramic Insulator CleaningREP98, REP9H
Mass Spec Source Cleaning Service at SISREP79
Finnigan MAT Ceramic Cleaning, SandblastingREP98, REP9H
