ASI QuickSplit™ Fixed Makeup-Flow Splitters

QuickSplit Flow Splitters	Makeup Overview	Fixed - Makeup	Adjustable - Makeup	Accessories

Each Fixed Makeup-Flow Splitter is individually tested and calibrated at the inlet flow and split ratio specified. These splitters will produce unde 500 psi backpressure with wate at their calibrated inlet flow rate. Backpressure and outlef flow rates will decrease or increase in proportion to ilet flow rate changes, the split ratio will remain constant. Split ratio accuracy is +/- 10% for all stated values.In order to assure <500 psi pressure drop across the splitter, please specify the actual inlet flow rate with your order if it deviates substantially from the calibration flow rate listed below.

Part No.	Inlet Flow Range	Split Flow	Calibration Flow & Split Ratio	est wt.	Quantity In Stock	Price
Fixed Makeup-Flow Splitter, UOM=EA
692PO0105	1-5mL/min.	5uL/min.	2mL/min.=400:1	0.25	0^{[*L]Standard lead-time for out-of-stock items is approximately two weeks depending on the item.}	$1995.00
692PO0110	1-5mL/min.	10uL/min.	2mL/min.=200:1	0.25	0^{[*L]Standard lead-time for out-of-stock items is approximately two weeks depending on the item.}	$1995.00
692PO0120	1-5mL/min.	20uL/min.	2mL/min.=100:1	0.25	0^{[*L]Standard lead-time for out-of-stock items is approximately two weeks depending on the item.}	$1995.00
692PO0150	1-5mL/min.	50uL/min.	2mL/min.=40:1	0.25	0^{[*L]Standard lead-time for out-of-stock items is approximately two weeks depending on the item.}	$1995.00
692PO0505	5-10mL/min.	5uL/min.	10mL/min.=2000:1	0.25	0^{[*L]Standard lead-time for out-of-stock items is approximately two weeks depending on the item.}	$1995.00
692PO0510	5-10mL/min.	10uL/min.	10mL/min.=1000:1	0.25	0^{[*L]Standard lead-time for out-of-stock items is approximately two weeks depending on the item.}	$1995.00
692PO0520	5-10mL/min.	20uL/min.	10mL/min.=500:1	0.25	0^{[*L]Standard lead-time for out-of-stock items is approximately two weeks depending on the item.}	$1995.00
692PO0550	5-10mL/min.	50uL/min.	10mL/min.=200:1	0.25	0^{[*L]Standard lead-time for out-of-stock items is approximately two weeks depending on the item.}	$1995.00
692PO1005	10-20mL/min.	5uL/min.	20mL/min.=4000:1	0.25	0^{[*L]Standard lead-time for out-of-stock items is approximately two weeks depending on the item.}	$1995.00
692PO1010	10-20mL/min.	10uL/min.	20mL/min.=2000:1	0.25	0^{[*L]Standard lead-time for out-of-stock items is approximately two weeks depending on the item.}	$1995.00
692PO1020	10-20mL/min.	20uL/min.	20mL/min.=1000:1	0.25	0^{[*L]Standard lead-time for out-of-stock items is approximately two weeks depending on the item.}	$1995.00
692PO1050	10-20mL/min.	50uL/min.	20mL/min.=400:1	0.25	0^{[*L]Standard lead-time for out-of-stock items is approximately two weeks depending on the item.}	$1995.00
692PO2005	20-50mL/min.	5uL/min.	50mL/min.=10000:1	0.25	0^{[*L]Standard lead-time for out-of-stock items is approximately two weeks depending on the item.}	$1995.00
692PO2010	20-50mL/min.	10uL/min.	50mL/min.=5000:1	0.25	0^{[*L]Standard lead-time for out-of-stock items is approximately two weeks depending on the item.}	$1995.00
692PO2020	20-50mL/min.	20uL/min.	50mL/min.=2500:1	0.25	0^{[*L]Standard lead-time for out-of-stock items is approximately two weeks depending on the item.}	$1995.00
692PO2050	20-50mL/min.	50uL/min.	50mL/min.=1000:1	0.25	0^{[*L]Standard lead-time for out-of-stock items is approximately two weeks depending on the item.}	$1995.00
692PO5005	50-150mL/min.	5uL/min.	100mL/min.=20000:1	0.25	0^{[*L]Standard lead-time for out-of-stock items is approximately two weeks depending on the item.}	$1995.00
692PO5010	50-150mL/min.	10uL/min.	100mL/min.=10000:1	0.25	0^{[*L]Standard lead-time for out-of-stock items is approximately two weeks depending on the item.}	$1995.00
692PO5020	50-150mL/min.	20uL/min.	100mL/min.=5000:1	0.25	0^{[*L]Standard lead-time for out-of-stock items is approximately two weeks depending on the item.}	$1995.00
692PO5050	50-150mL/min.	50uL/min.	100mL/min.=2000:1	0.25	0^{[*L]Standard lead-time for out-of-stock items is approximately two weeks depending on the item.}	$1995.00
692POCSCS	Custom	Custom	---	0.25	0^{[*L]Standard lead-time for out-of-stock items is approximately two weeks depending on the item.}	$2095.00
[*L] Standard lead-time for out-of-stock items is approximately two weeks depending on the item.
Ordering information. International (non-US) prices available through your local dealer.
