F69
A & N ULRIC
TM
Flange System
Scientific Instrument Services, Inc.
TM
FAX: 908-806-6631
www.sisweb.com/catalog/08/F69
ULRIC Aluminum Clamp
ULRIC Stainless Steel Clamp
ULRIC Socket Weld Flange
-
ULRIC
TM
clamp with
wing nut and
ss/trim, 3/4" - 2"
-
For elastomer and
metal seal
Part No.
Tube Size
A
B
1/2" & 3/4"
2"
5/8"
1"2 1/2"5/8"
1 1/2"3 3/4" 3/4"
2"4 1/4"7/8"
-
ULRIC
TM
clamp
- all stainless steel
with hex nut
3/4" - 2"
-
For elastomer and
metal seal
-
High Temperature - ultra high vacuum applications
Part No.
Tube Size
A
B
1/2" & 3/4"
2"
5/8"
1"2 1/2"5/8"
1 1/2"3 3/4" 3/4"
2"4 1/4"7/8"
A
B
A
B
-
304 Stainless
-
Internal Weld
-
Self Aligning
-
Accepts Standard
Tubing
Part No.
Tube Size
A
B
C
D
3/4"
.760" .500".200".875"
1"1.010"
.500"
.200"
1.250"
1 1/2"1.510"
.500"
.210"
1.750"
2"2.010"
.620"
.225"
2.250"
A
B
D
C
ULRIC Half Nipple
-
304 Stainless
-
Usable as half
nipple
-
Butt Weld
Part No.
Tube Size
A
B
C
1/2".500".065" 1.575"
3/4".750".065" 1.575"
1"1.000"
.065" 1.575"
1 1/2"1.500" .065"
1.575"
2"2.000"
.065" 1.575"
C
B
A
ULRIC Flange - Unbored Stub
-
304 Stainless
-
Machine bore or
tap application
-
May be welded
Part No.
A
B
.750".500"
1.250".500"
1.750".500"
2.250".620"
B
A
ULRIC Flange - Blank
ULRIC Adaptive Elastomer Seal Assembly
3/4" - 2"
-
304 Stainless
-
Replaceable "O"
ring
-
Adapts ULRIC
TM
to
ISO
-
Buna "N"
- 100°C max
-
Viton - 200°C max
-
Silicone - 200°C
max Chemically
Resistant
Part Numbers
A
B
Viton
Buna
Silicone
A
B
-
304 Stainless
-
To close off unused
ports
-
Not recommended
for welding but
may be modified (Use unbored stub)
Part No.
A
.3"
.3"
.3"
.3"
A
tip...
