E79
ASI HyperShear
TM
HPLC Mixers
Scientific Instrument Services, Inc.
TM
FAX: 908-806-6631www.sisweb.com/catalog/08/E79
Combo micro Series - Stainless Steel, Biocompatible PEEK
TM
Ordering Information
You can choose any 2, 3 or 4 cartridge combination from 0.5µL, 1µL, 2µL,
5µL, 10µL, and 25µL mixer cartridges to create the desired volume to fit your
application. The minimum volume you can create will be 2 x 0.5 µL cartridge
combination and the maximum volume will be 4 x 25 µL cartridge combination.
You will be able to create almost the exact volume you need within that range.
The Application and Use of ASI Combo Micro Static Mixers
Chromatographers seeking to optimize mixing vol-
umes at flow rates below 100 µL/min. now have the
ability to customize a mixing volume which is perfectly
tuned to match the separation system. Choosing the
right mixing volume is always a compromise between
absolute noise reduction, delay volume, and gradient
distortion. Ideally the optimum mixing volume should be
determined experimentally by evaluating several mixing
volumes to determine which provides optimum chro-
matographic performance. For the separation below at
50 µL/min., a 50 µL mixer contributes too much delay
volume and gradient distortion. The ASI Combo 35µL
(25µL + 10µL) mixer provides just the right balance
between noise reduction and gradient performance.
Part No.
Description
In-Line Combo 1.0 µl volume 2 Mixer
In-Line Combo 2.0 µl volume 2 Mixer
In-Line Combo 3.0 µl volume 2 Mixer
In-Line Combo 4.0 µl volume 2 Mixer
In-Line Combo 10.0 µl volume 2 Mixer
In-Line Combo 15.0 µl volume 2 Mixer
In-Line Combo 30.0 µl volume 2 Mixer
In-Line Combo 20.0 µl volume 2 Mixer
In-Line Combo 50.0 µl volume 2 Mixer
In-Line Combo 1.5 µl volume 3 Mixer
In-Line Combo 2.0 µl volume 3 Mixer
In-Line Combo 3.0 µl volume 3 Mixer
In-Line Combo 4.0 µl volume 3 Mixer
In-Line Combo 5.0 µl volume 3 Mixer
In-Line Combo 10.5 µl volume 3 Mixer
In-Line Combo 15.5 µl volume 3 Mixer
In-Line Combo 20.5 µl volume 3 Mixer
In-Line Combo 30.5 µl volume 3 Mixer
In-Line Combo 35.5 µl volume 3 Mixer
In-Line Combo 40.0 µl volume 3 Mixer
In-Line Combo 55.0 µl volume 3 Mixer
In-Line Combo 2.0 µl volume 4 Mixer
In-Line Combo 3.0 µl volume 4 Mixer
In-Line Combo 4.0 µl volume 4 Mixer
In-Line Combo 5.0 µl volume 4 Mixer
In-Line Combo 6.0 µl volume 4 Mixer
In-Line Combo 7.0 µl volume 4 Mixer
In-Line Combo 8.0 µl volume 4 Mixer
In-Line Combo 9.0 µl volume 4 Mixer
In-Line Combo 10.0 µl volume 4 Mixer
In-Line Combo 20.0 µl volume 4 Mixer
In-Line Combo 25.0 µl volume 4 Mixer
In-Line Combo 40.0 µl volume 4 Mixer
In-Line Combo 50.0 µl volume 4 Mixer
In-Line Combo 100.0 µl volume 4 Mixer
Part No.
Description
In-Line Combo 1.0 µl volume 2 Mixer
In-Line Combo 2.0 µl volume 2 Mixer
In-Line Combo 3.0 µl volume 2 Mixer
In-Line Combo 4.0 µl volume 2 Mixer
In-Line Combo 10.0 µl volume 2 Mixer
In-Line Combo 15.0 µl volume 2 Mixer
In-Line Combo 30.0 µl volume 2 Mixer
In-Line Combo 20.0 µl volume 2 Mixer
In-Line Combo 50.0 µl volume 2 Mixer
In-Line Combo 1.5 µl volume 3 Mixer
In-Line Combo 2.0 µl volume 3 Mixer
In-Line Combo 3.0 µl volume 3 Mixer
In-Line Combo 4.0 µl volume 3 Mixer
In-Line Combo 5.0 µl volume 3 Mixer
In-Line Combo 10.5 µl volume 3 Mixer
In-Line Combo 15.5 µl volume 3 Mixer
In-Line Combo 20.5 µl volume 3 Mixer
In-Line Combo 30.5 µl volume 3 Mixer
In-Line Combo 35.5 µl volume 3 Mixer
In-Line Combo 40.0 µl volume 3 Mixer
In-Line Combo 55.0 µl volume 3 Mixer
In-Line Combo 2.0 µl volume 4 Mixer
In-Line Combo 2.0 µl volume 4 Mixer
In-Line Combo 2.0 µl volume 4 Mixer
In-Line Combo 2.0 µl volume 4 Mixer
In-Line Combo 2.0 µl volume 4 Mixer
In-Line Combo 2.0 µl volume 4 Mixer
In-Line Combo 2.0 µl volume 4 Mixer
In-Line Combo 2.0 µl volume 4 Mixer
In-Line Combo 2.0 µl volume 4 Mixer
In-Line Combo 2.0 µl volume 4 Mixer
In-Line Combo 2.0 µl volume 4 Mixer
In-Line Combo 2.0 µl volume 4 Mixer
In-Line Combo 2.0 µl volume 4 Mixer
In-Line Combo 2.0 µl volume 4 Mixer
In-Line Complete Assembly - 2, 3, or 4 Cartridge
Combination and Housing
Biocompatible PEEK - HP is not available
In-Line Assemblies - Port Size: 10-32 CPI (Standard HPLC Fittings for 1/16" Tube)
tip...
