Finally, true, trouble-free quick-connect hardware for HPLC!
W
hat's new from the innovators at Optimize Technologies? Opti-LynxTM! The world's only low dispersion, high pressure quick
connect system for HPLC is now available from S.I.S.
Now you can make and break High Pressure connections in seconds or reconfigure your HPLC system without tools. A quarter turn
is all you need to assure leak-free connections to your analytical column, in-line filters, guard column or anywhere you frequently change
components.
Here's how it works:
OPTI-LYNX Column Connector Kit
When a guard column is not required, OPTI-LYNX Column Connector Kit brings quick-connect convenience to any 10-32 analytical
column. Use one Column Connector Kit at the top of the column for fast and easy connection with integral pre-column filtration, and
another at the bottom of the column with a sealing element for a straight-through connection to the detector cell.
The basic holder set is the same whether or not you require filtration. Simply add the correct two letter extension to the part number
below -- CD or CE for PEEK-encased stainless steel filters, or AB for Sealing Elements.
Start by connecting your existing tubing to an
OPTI-LYNX Holder Cap using the included fingertight fitting.
Then, tighten a slotted Holder Tube into the Holder cap.
There are two Holder Tubes of different lengths to choose
from --one for OPTI-LYNX guard column cartridges, and one
for filtration elements and straight-through (union)
connections.
When it's time to bring the two halves of
OPTI-LYNX together for a high-pressure, quick-connect seal,
all you need is an OPTI-LYNX insert. Choose a guard column
cartridge, a precolumn or in-line filter, or a sealing element for
straight-through connection.
Opti-LynxTM Column Connector Kit
with Sealing Element
Part No.
Description
Opti-Lynx Connector Kit
Includes: Universal Port Adapter, Holder Cap/Holder Tube, 1 Sealing Element
1
4
2
For every plug, there's a socket, and for every OPTI-
LYNX Holder Tube, there's a Bayonet Connector. We have
Bayonets for making ZDV connections to any analytical
column (our Universal Port Adapter) and Bayonets that adapt
to 10-32 fingertights, for use in-line anywhere on your HPLC
system.
3
