Optimize Technologies Trap Cartridges
E6
Scientific Instrument Services, Inc.
TM
Phone: 908-788-5550
OPTI-LYNX
TM
Trap Cartridges
B
uilt on the OPTI-LYNX quick-connect platform, OPTI-LYNX trap cartridges provide a versatile, easy-to-use cartridge based trap-
ping system. Each cartridge shares the same external dimensions, so that switching chemistries or capacities is only a matter
of a quarter-twist.
OPTI-LYNX traps are packed with special large particle silica and polymeric based materials to strike the perfect compromise between
sample capacity and backpressure. This choice of material gives OPTI-LYNX trap users a myriad of sample processing options. An OPTI-
LYNX trap cartridge may be set up in the loop of an injection or switching valve to facilitate on-line trapping. Alternatively, the large parti-
cle size is amenable to off-line, hand-loading applications. You can even combine the two: loading a trap off-line and then installing it in
your LC for elution directly into the solvent flowpath.
OPTI-PAK
TM
Capillary Trap Cartridges
T
he OPTI-PAK Capillary Trap Cartridge utilizes the ultimate in engineering and fluidic design to deliver a trap column that is both
easy to use, and extremely effective.The OPTI-PAK is specially designed for use in today's low volume applications. With bed
volumes ranging from 0.12 無 to 5.0 無, you can be sure to find the perfect balance between sample capacity and trap volume.
A packed stem, enabled by a proprietary method of frit placement, places the packed bed directly into the flowpath, eliminating all excess
swept volume. Less swept volume translates to an absolute minimum in sample dilution and dispersion. The unique hardware design inte-
grates a PEEK holder with an auto-adjusting stem that fluidly interfaces to any 10-32 port, providing a zero-dead-volume connection no
matter what the tube stop depth.
Sorbent
Part No.
Bed
C18
C18AQ
C8
C4
SCX
SAX
DVB
10-03328-
**
0.12 無
10-03328TG
10-03324-
**
0.25 無
10-03317-
**
0.50 無
10-03317TE
10-03317TG
10-03225-
**
1.00 無
10-03229-
**
2.00 無
10-03233-
**
5.00 無
Two Letter Packing CodeTA
TB
TC
TD
TE
*Use the trap cartridge code table above to find the seven digits that match the bed/volume you require. then find the two letter packing code for your sorbent phase.
Example: a five pack of 0.5 無 trap cartridges with SCX sorbent would have a part number 10-03317-TE.
OPTI-PAKTMTrap Cartridges, 5pk
Part No.
Description
Opti-Lynx In-Line Trap Cartridge Holder
Includes: Bayonet Connector, holder cap/tube, fittings
(Trap Cartridges are sold separately - use table below
to find your part number.)
Tube Set, for OPTI-LYNX Trap Cartridges
(Rheodyne Injection Valve)*
Tube Set, for OPTI-LYNX Trap Cartridges
(Valco Injection Valve)*
*These tube sets come with two 30 cm lengths of 0.003" ID PEEK tubing and 2 valve port fittings designed for use with
the specified injection valve. Can also be used for making in-line connections.
Sorbent
Part No.
Bed
C18
SCX
C18AQ
SAX
C8
C4
DVB
11-02868-
**
4 無
11-02870-
**
20 無
11-02872-
**
40 無
11-02874-
**
100 無
Two Letter Packing Code
TA
TB
TD
TE
*Use the trap cartridge code table above to find the seven digits that match the bed/volume you require. then find the two letter packing code for your sorbent phase.
Example: a five pack of 20 無 trap cartridges with SCX sorbent would have a part number 11-02870-TB.
OPTI-LYNXTMTrap Cartridges, 5pk
OPTI-LYNX Trap Holder Hardware
Optimize Technologies special-
izes in custom packing solu-
tions. Please contact us if you
do not see the phase/sorbents
you require.
Optimize Technologies special-
izes in custom packing solu-
tions. Please contact us if you
do not see the materials you
require.
Part No.
Description
Tube Set, for OPTI-PAK Trap Cartridges
(Rheodyne Injection Valve)*
Tube Set, for OPTI-PAK Trap Cartridges
(Valco Injection Valve)*
*These tube sets come with one 30 cm length of 0.003" ID PEEK tubing and a valve port fitting designed for use with
the specified injection valve. Can also be used for making in-line connections.
OPTI-LYNXTMTrap Holder Hardware
TF
TF
TG
TH
TG
