SIS Catalog Online

Protocol Station Regulator

D68

Scientific Instrument Services, Inc.

™

Phone: 908-788-5550

www.sisweb.com/catalog/08/D68

Protocol Station Regulator

Features

•

Wall Mounted Regulator

•

Convenient Safe Charging Gas Tanks

•

3’ Stainless Steel Pigtail with Gas Cylinder
Fittings

•

Choice of Brass or Stainless Steel Construction

•

Available with Single and Dual Stage Regulators

T

he Protocol Station is a regulator option designed for the
convenient wall mounting of a Concoa High Purity
regulator. Wall mounting of a regulator provides ease of

use, prevents regulator damage and improves safety. The Protocol
Station is available in brass or 316 Stainless Steel construction as
specified by the regulator series. This option comes complete with
a 3 foot long flexible all stainless steel pigtail with armor casing.
The CGA connection on the pigtail has an integral check valve in
the gland to prevent internal contamination during cylinder change
out. Should purging be desired the gas block comes with a plugged
port which can be removed for the assembly of a diaphragm valve.
The bracket mounts conveniently to any surface.

Materials of Construction
Gas Block:

316 Stainless Steel or Brass Barstock

Pigtail:

316 Stainless Steel inner- core
316 Stainless Steel Braid (2 layers)
304 Stainless Steel armor casing

CGA Connections:

316 Stainless Steel or Brass Barstock

Check Valve O’Ring

Viton (other materials available on request)

Specifications

Maximum Inlet Pressure:

3000 psi

Operating Temp. Range:

0° F to 120° F

Outlet Pressure Range:

0-100 psi

Inlet gauge:

0-4000 psi

Description

Part No.*

Single stage Brass Barstock regulator with wall mount protocol station,

4023321CGA580

0-100 psi outlet, 3’ stainless steel pigtails with CGA outlet to tank

4023321CGA350

4023321CGA590

Dual stage Brass Barstock regulator with wall mount protocol station,

4123321CGA580

0-100 psi outlet, 3’ stainless steel pigtails with CGA outlet to tank

4123321CGA350

4123321CGA590

Single stage 316 Stainless Steel, regulator with wall mount protocol station,

4223321CGA580

0-100 psi outlet, 3’ stainless steel pigtails with CGA outlet to tank

4223321CGA350 Part #4223321CGA350--Click to order
Current Price: $1160.00
Unit of Measure: EA
Est. Ship Weight=3 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.

4223321CGA590

Dual stage 316 Stainless Steel, regulator with wall mount protocol station,

4323321CGA580 Part #4323321CGA580--Click to order
Current Price: $1383.00
Unit of Measure: EA
Est. Ship Weight=3 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.

0-100 psi outlet, 3’ stainless steel pigtails with CGA outlet to tank

4323321CGA350 Part #4323321CGA350--Click to order
Current Price: $1383.00
Unit of Measure: EA
Est. Ship Weight=3 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.

4323321CGA590

*

CGA Fitting

For Gases

580

Helium

350

Hydrogen

590

Air

Other fittings available on special request.
