Capillary Column Splitters
D36
Scientific Instrument Services, Inc.
™
Phone: 908-788-5550
www.sisweb.com/catalog/08/D36
•
Designed for splitting the flow from one capillary column to
two detectors
•
Glass lined tubing (GLT
™
) splitter union for inertness
•
Splitter is supplied complete with tubing, ferrules and nuts
required for installation
•
Can be used for 0.1 - 0.32mm I.D. capillary columns
•
For and outlet splitter for 0.53mm I.D. columns,
Part No. 123634
Part #123634--Click to order
Current Price: $247.00
Unit of Measure:
EA
Est. Ship Weight=1 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.
is recommended
Fixed outlet splitter for capillary columns
T
he splitter will provide ratios from 1:1 up to 1:10 by
selecting appropriate lengths of the fused silica trans-
fer lines to the detectors. (If the transfer line lengths
and ID's are the same, a 1:1 split will be achieved).
The VSOS consists of a special GLT™ union with locknut,
0.4mm ID two-hole ferrules (GVF2/004), 0.5mm ID single-hole
ferrules (GVF/005) and a 5 metre length of 0.22mm ID deacti-
vated fused silica tubing.
W
here an injected sample is to be split
between two capillary columns for
simultaneous analysis, the fixed inlet
splitter is recommended. The low internal volume,
glass lined tubing design ensures an inert low dead
volume connection.
The two capillary columns used (usually differing
in polarity) must have the same length and inside
diameter to obtain equal sample splitting.
Three kits are available to suit 0.22, 0.32 and
0.53mm I.D. capillary columns. The kits consist of a
special GLT
™
lined union and all ferrules required for
installation.
Part No.
Column I.D.
Pack Size
Inlet Capillary Column Splitter
123632
Part #123632--Click to order
Current Price: $247.00
Unit of Measure:
EA
Est. Ship Weight=1 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.
0.1 - 0.25mm
1
123633
Part #123633--Click to order
Current Price: $247.00
Unit of Measure:
EA
Est. Ship Weight=1 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.
0.32mm
1
123634
Part #123634--Click to order
Current Price: $247.00
Unit of Measure:
EA
Est. Ship Weight=1 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.
0.45 - 0.53mm
1
Replacement Ferrules
072662
Part #072662--Click to order
Current Price: $60.00
Unit of Measure:
PK
Est. Ship Weight=0.25 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.
0.1 - 0.25mm (2 hole ferrule)
10
072664
Part #072664--Click to order
Current Price: $62.00
Unit of Measure:
PK
Est. Ship Weight=0.25 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.
0.32mm (2 hole ferrule)
10
072655
Part #072655--Click to order
Current Price: $40.00
Unit of Measure:
PK
Est. Ship Weight=0.25 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.
0.45 - 0.53mm (1 hole ferrule)
10
Splitter
Deactivated
Fused Silica
Column 1
Column 2
Injector
Splitter
Detector 1
Detector 2
Column
Injector
•
Splits an injection between two capillary
columns
•
Fixed split ratio
•
Detector sensitivity is maintained
•
Splitter is supplied complete with tubing,
ferrules and nuts required for installation
•
Inert glass lined tubing (GLT
™
) flow path
•
Low dead volume
•
Can be used for all capillary columns
(0.1 - 0.53mm I.D.)
Fixed Inlet Splitter for Capillary Columns
Description
Part No.
Ratio
Pack Size
Outlet Capillary Column Splitter
User-determined Split Ratio*
1861460
Part #1861460--Click to order
Current Price: $172.00
Unit of Measure:
EA
Est. Ship Weight=1 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.
1:1**
1
1861461
Part #1861461--Click to order
Current Price: $172.00
Unit of Measure:
EA
Est. Ship Weight=1 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.
1:5**
1
1861462
Part #1861462--Click to order
Current Price: $172.00
Unit of Measure:
EA
Est. Ship Weight=1 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.
1:10**
1
Replacement Tubing
18614600
Part #18614600--Click to order
Current Price: $66.00
Unit of Measure:
EA
Est. Ship Weight=1 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.
1:1**
2
18614610
Part #18614610--Click to order
Current Price: $54.00
Unit of Measure:
EA
Est. Ship Weight=1 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.
1:5**
2
18614620
Part #18614620--Click to order
Current Price: $54.00
Unit of Measure:
EA
Est. Ship Weight=1 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.
1:10**
2
Replacement 2-Hole Ferrules
072662
Part #072662--Click to order
Current Price: $60.00
Unit of Measure:
PK
Est. Ship Weight=0.25 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.
0.1 - 0.25mm I.D. Column
10
072664
Part #072664--Click to order
Current Price: $62.00
Unit of Measure:
PK
Est. Ship Weight=0.25 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.
0.32mm I.D. Column
10
*Includes 5 meter length of 0.22mm I.D. deactivated fused silica tubing.
**Includes fused silica tubing pre fused into a 2-holed ferrule for preset split ratios.
