Glassware for Use in Purging Samples
C30
Scientific Instrument Services, Inc.
™
Phone: 908-788-5550
www.sisweb.com/catalog/08/C30
•
Large selection of round bottom
flasks and Erlenmeyer flasks
•
For use in purging large volume
liquid or solid samples
•
Adapters available for trapping
on S.I.S. GLT desorption
tubes
•
Constructed of
Borosilicate glass
•
Flask necks are 24/40
ground glass
female fittings
164372
Purge Head Adapter, PTFE 24/40
Liquid Purge Head, Tube style
Flat Bottom Flasks
Erlenmeyer Flasks, Flat Bottom
Adapters and Accessories
T
he following glassware can be
used in conjunction with the
S.I.S. purge head adapter to
permit the use of the S.I.S. tube style liq-
uid purge head for purging liquid and solid
samples and trapping volatiles purged
from the samples onto the S.I.S. GLT
Thermal Desorption Tubes. The following
glassware all have 24/40 ground glass
necks. The PTFE Purge Head Adapter
seals into this ground glass fitting and its
1/4" diameter 'O' Ring seal accepts the
Tube Style Liquid Purge Head. This Tube
Style Purge Head described previously
permits both the introduction of the purge
gas to purge the volatiles from the sample
and the trapping of these volatiles on the
GLT desorption tubes.
Round Bottom Flasks
PTFE Purge
Head Adapter
PTFE Purge
Head Adapter
Tube Style
Purge Head
635926
Erlenmeyer Flask
125 ml
LG7750130
Erlenmeyer Flask
500 ml
428126
Flat Bottom Flask
125 ml
428146
Flat Bottom Flask
250 ml
428164
Flat Bottom Flask
500 ml
Part No.Description
Size (ml)
LG7220140
Round Bottom Flask
50 ml
LG7220142
Round Bottom Flask
100 ml
LG7220146
Round Bottom Flask
200 ml
LG7220148
Round Bottom Flask
250 ml
LG7220152
Round Bottom Flask
500 ml
LG7220154
Round Bottom Flask
1000 ml
LG7220156
Round Bottom Flask
2000 ml
