SIS Catalog Online

A81

High Temperature Epoxies

Scientific Instrument Services, Inc.

™

FAX: 908-806-6631

www.sisweb.com/catalog/08/A81

500°F Adhesive and Electrically
Resistant Epoxy for all Applications

Ultra Temp. 600°F Adhesive and
Electrically Resistant Epoxy

The Ultimate in High Temperature Epoxy Technology.

Duralco 4700 properties are based on a unique cross linked

inorganic - organic polymer.

Duralco 4700 provides excellent heat stability, moisture,

chemical, solvent and electrical resistance.

4700 is a superior adhesive with high electrical resistance and

High-Bond strength.

It is ideal for electronics, instrumentation, and appliance

industries.

It is used for bonding, potting, repairs, molds, etc. and for

applications requiring 600°F service. It is specified for bonding
aerospace components providing electrical insulation from -65°F
to +600°F.

Part No.

Description

4525-KT Part #4525KT--Click to order
Current Price: $89.95
Unit of Measure: EA
Est. Ship Weight=3 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.

Duralco 4525 Pint Trial Kit - All purpose
adhesive & electrical - room temp. cure

4700-KT Part #4700KT--Click to order
Current Price: $85.95
Unit of Measure: EA
Est. Ship Weight=3 lbs
Not in stock. Standard lead time for out-of-stock items is approximately two weeks.

Duralco 4700 Pint Trial Kit - Ultra Temp.
potting & adhesive - high temp. cure

C

otronics’ Unique Catalytically Cured Duralco 4525 Low

Shrinkage System, provides the highest temperature prop-
erties to be obtained with a simple room temperature cure.

Duralco 4525 provides excellent adhesion and electrical

properties and has the lowest moisture absorption required for
many critical electronic applications.

Duralco 4525 contains no solvents or volatiles. It is machin-

able and resistant to corrosion, radiation, all common chemicals
and solvents.

No more complicated, costly and time consuming heat cures.

Just apply and cure at room temperature.

Extensively tested and used in hydrochloric, phosphoric, sul-

furic, and nitric acids, as well as in caustic and chromic oxide
solutions for use in the chemical processing industries.

4525 is being used for high performance bonding, potting,

sealing, coatings, repairs, castings and jigs. It is found in appli-
ances, instrumentation, motors, equipment, etc.

Properties

4525

4700

Maximum Temp. °F

500

600

Density gm/cc

1.9

1.94

Hardness Shore D

80

94

Tensile Strength psi

10,000

11,100

Thermal Conductivity

13

Thermal Expansion 10

-5

/°C

6.4

Dielectric Strength Volts/mil

500

555

Volume Resistivity ohm

•

cm

10

15

10

16

Heat Distortion

210°C

300°C

Viscosity cps

Paste

Dissipation Factor 100/kc

0.010

Dielectric Constant 100 kc

3.5

Elongation

2%

Thermal Stability
1000 hr @ 200° C

0.05%

0.02%

Shrinkage Moisture
Absorbity 30 days @ 50°C

0.05%

0.02%

Cure

16 hr @ RT

4 hr @225°F

& 2 hr @ 350°F
