A31
Temperature Controllers
Scientific Instrument Services, Inc.
TM
FAX: 908-806-6631
www.sisweb.com/catalog/08/A31
Applications:
B
riskHeat Digital PID Thermocouple Temperature
Controllers (BriskONE Series) are designed for indoor
general purpose use, for remote or portable applica-
tions, which require precise automatic control of heaters. Typical
applications include temperature control of small tanks, laborato-
ry heaters, semiconductor processed, drums, pipes, freeze pro-
tection, process control and moisture protection systems or other
applications requiring precise control.
BriskHeat
®
digital PID Thermocouple Temperature Controller
Specifications:
-
Accuracy: ±0.25% of reading ±1 least significant digit
-
Operating voltage 120, 240VAC, + 10% -15%,
50-400hz
-
Rated 15A @120VAC, 10A @240VAC
-
Operating range 32-1400°F (0-760°C)
-
Maximum controller exposure temperature 14°F
(-10°C) 122°F (50°C)
-
Table top design with otional unistrut mounting
bracket
-
Fused output
-
Type J thermocouple input
-
Dual display shows set point and actual process
temperature
-
Programmable to either °C or °F
-
Fuzzy logic reduces overshoot on startup
-
Automatic tuning of PID parameters
-
Sensor break protection with average output option
to continue process heating
-
Auto/manual control ability
-
16 segment ramp/soak
-
Compact size
-
Simple 4 key user control
-
User programmable alarm types
-
Program security lock levels
Part Number
Volts
Amps
120VAC
15
240VAC
10
Mating power connector
Accessories
Owners manual
120 VAC input power cord with 2p 3w plug
240 VAC input power cord with 2p 3w plug
15 Amp fuse
10 Amp fuse
Unistrut mounting bracket
120 VAC output adapter cord
240 VAC output adapter cord
J Style Thermocouple
Part Number
Length
5'
10'
25'
tip...
