Detech 340 Electron Multiplier

DeTech multipliers are manufactured from a lead glass suitably processed to yield an efficient secondary emitting layer on the inner surface. Each electron multiplier is tested before shipment to ensure its performance is within specification. Each multiplier is delivered with a quality control indicating its model number, test voltage, gain at that voltage, bias current at the test voltage and the date of shipment.

[1] Detech 340 Multiplier (SIS Part #340)
For use on instruments:
Thermo Finnigan OWA® 1020/5100
Notes: Base. OWA style after 8/81.
Warranty: 100% non-nonsense warranty. If any customer is unsatisfied with a DeTech multiplier, the multiplier is replaced immediately with no questions asked and regardless how long the multiplier has been on the customer's shelf.
Model Number 340
Maximum Bake Temperature 300 oC
Maximum Operating Temperature 200 oC
Mode of Operation Analog
Typical Gain at 2650 Volts 1 x 107
Typical Bias current >18 Micro Amps
Resistance 100-150 Meg Ohms
Maximum Linear Output Current 10% of Bias Current
Dark Current <1 x 10-12 Amps
Part No. Description UOM Picture est
wt.
Quantity
In Stock
Price Quantity
to order
340 Detech 340 Electron MultiplierEAthumbnail 2 0[*L]Standard lead-time for out-of-stock items is approximately two weeks depending on the item. $748.00[*B][*B] 3 or more: 5% off; 10 or more: 7% off.
Bulk quantity discounts on marked items:
[*B] 3 or more: 5% off; 10 or more: 7% off.
[*L] Standard lead-time for out-of-stock items is approximately two weeks depending on the item.
shopping cart Ordering information. International (non-US) prices available through your local dealer.
SIS Catalog Cross Reference
Page #Part Numbers
A41 - DeTech Electron Multipliers for Thermo Systems 340
